Backlit Led Panel Light-0
*High quality SMD2835 chip, high CRI>80Ra, high luminous efficiency >100lm/w; *LED panel light 1200x300 is with 36w, 40w for your choose, also welcome OEM; *Professional acrylic transmitting plate, back-lit type, non-leakage and no dark area; *Body in one-piece stretch aluminum, sand white finish frame, perfected merging with a variety ceiling; *Plug-in design driver is with simple structure and more safe; *Suitable for recessed installation in commercial applications where a suspended grid ceiling is installed, Backlit LED Panels deliver excellent savings over traditional fluorescent light fittings while delivering improved lumen output.
Light Source: | LED | Input Voltage(V): | AC85-285V | Material: | Aluminum | IP Rating: | Other | Model Number: | BY-LT001 |
---|
Item No | Wattage | Dimension (mm) |
Voltage | CCT | Light Efficiency (LM/W) |
CRI | Housing Color | Beam Angle | Warranty |
BY-LPB6060-40W | 40W | 600*600*30mm | AC220-240V | 2800-6500K | >100LM/W (Actural Value) |
Ra>80 | White&Silver | >1200 | 2 Years |
BY-LPB6060-48W | 48W | 600*600*30mm | AC220-240V | ||||||
BY-LPB1230-40W | 40W | 300*1200*30mm | AC220-240V | ||||||
BY-LPB1260-80W | 80W | 600*1200*30mm | AC220-240V | ||||||
BY-LPB3030-20W | 20W | 300*300*30mm | AC220-240V | ||||||
BY-LPB3060-20W | 20W | 300*600*30mm | AC220-240V |
